Technical Specifications
MBR Systems Engineered to Your Exact Requirements
Newterra’s membrane bioreactor systems are available in a range of pre-engineered, remote, and fully custom configurations to match your site’s flow, capacity, and compliance needs. Whether you’re evaluating system footprints, effluent quality targets, or deployment options, the technical details below give you everything you need to find the right fit.
The Technical Foundation Behind Every Newterra MBR System
Newterra’s MBR systems are engineered to meet some of the most demanding effluent standards in domestic and industrial wastewater treatment. At the core of every system are world-class ultrafiltration membranes paired with biological treatment — a combination that consistently delivers clean, reusable-quality water regardless of influent variability or site conditions.
Effluent Quality Across Every System
Our systems are proven across a wide range of applications where high-quality effluent is required, including treatment of:
- Domestic wastewater treatment
- Industrial process and discharge compliance
- Water reuse and recycling programs
- Regulated discharge to sensitive receiving environments
- Remote and off-grid community water management
| Parameter | Target Performance |
|---|---|
| Biological Oxygen Demand (BOD) | <5.0 mg/L |
| Total Suspended Solids (TSS) | <5.0 mg/L |
| Ammonia-N | <1.0 mg/L |
| Turbidity | <0.2 NTU |
| Total Phosphorus | <0.05 mg/L* |
| Total Nitrogen | <3.0 mg/L* |
*With nutrient removal options included, subject to influent characteristics
Clear³ MBR.ST Configurable Membrane Bioreactor Decentralized Systems
Pre-Engineered Configurable system providing a compact, low cost and fast deployment solution.
| Model | Market | Flow M3/D | GPD | Footprint | |
|---|---|---|---|---|---|
| Clear3 MBR.ST-35 | Mobile Home, Recreation, Seasonal | 35 | 9,200 | 8’x20′ | MBR.ST-35 |
| Clear3 MBR.ST-105 | Mobile Home, Recreation, Seasonal, Housing Developments | 105 | 27,700 | 8’x40′ | MBR.ST-105 |
| Clear3 MBR.ST-225 | Residential, Recreational, Institutional and Commercial Developments | 225 | 59,400 | 16’x40′ | MBR.ST-225 |
| Clear3 MBR.ST-450 | Residential, Recreational, Institutional and Commercial Developments | 450 | 118,800 | 32’x40′ | MBR.ST-450 |
| Clear3 MBR.ST-900 | Residential, Recreational, Institutional and Commercial Developments | 900 | 237,700 | 40’x40′ | MBR.ST-900 |
Clear³ MBR.WWT Modular Membrane Bioreactor Remote Systems
Self-contained systems for remote/off the grid locations, providing independent, portable and low maintenance solutions.
| Model | Market | Flow M3/D | GPD | Footprint | |
|---|---|---|---|---|---|
| Clear3 MBR.WWT 7 | Remote Systems with up to 30 people | 7.5 | 1,980 | 8’x20′ | MBR.WWT 7 |
| Clear3 MBR.WWT 12 | Remote Systems with up to 50 people | 12 | 3,300 | 8’x40′ | MBR.WWT 12 |
| Clear3 MBR.WWT 25 | Remote Systems with up to 100 people | 25 | 6,600 | 16’x40′ | MBR.WWT 25 |
| Clear3 MBR.WWT 50 | Remote Systems with up to 200 people (scalable to 800 people) | 50 | 13,200 | 32’x40′ | MBR.WWT 50 |
| Clear3 MBR.WWT 125 | Remote Systems with up to 500 people | 125 | 33,000 | 16’x120′ | MBR.WWT 125 |
MBR Custom Membrane Bioreactor Systems
When standard configurations aren’t enough, Newterra’s MBR.MF series delivers fully custom-engineered solutions for municipal and industrial applications from 100,000 GPD up to 1.5 MGD and beyond. Each system is designed from the ground up around your specific influent characteristics, site constraints, and regulatory requirements. Modular skid-mounted construction keeps installation efficient while allowing future capacity expansion without major retrofits — so your system grows with your needs.
