CANSORB P High Pressure Liquid Phase Active Carbon Adsorbers
Newterra CANSORB P High-Pressure, Liquid Phase Activated Carbon Adsorption Systems are fabricated with vessel quality carbon steel to ASME code and are NSF/ANSI 61 Certified.
Granular Activated Carbon (GAC) and Filter Media
Newterra supplies a range of bulk granular activated carbon (GAC) for liquid and vapor phase adsorption.Whether you need virgin coconut, coal-based, or reactivated GAC media, Newterra delivers the right activated carbon solution for your application. In addition to carbon, Newterra supplies active filter media for the removal of organics, trace metals, oil, and suspended solids across liquid and vapor treatment applications.
Product Overview
Granular Activated Carbon Media
- Newterra has an extensive line of granular activated carbon (GAC) filter media for liquid phase and vapor phase adsorption applications.
- We supply virgin coconut activated carbon, coal-based GAC, and reactivated carbon for various adsorption processes.
- We deliver carbon in amounts ranging from 55 lb bags to bulk-activated carbon orders in the tens of thousands of pounds.
Active Media
- Our oil absorption media consists of either modified clay or zeolite. Oil absorption media can remove 80-90% of the undissolved oil in an influent water stream.
- Trace metal removal media is available for liquid-phase applications. All trace metal removal media can produce greater than 90% removal efficiencies for adsorbates
Non-Active Media
- The Newterra Gravel and Sand Filtration Media can reduce suspended solids in applications with particles above 10 microns. Smaller particles down to 5 microns may be controlled using garnet or zeolite. Packages are available with anthracite to increase capacity.
We’re Here to Support You
We understand your unique challenges. Beyond a technology solution, Newterra is dedicated to the entire lifecycle of your needs. Whatever support you need, Newterra probably has a solution to solve it..
Rental and Alternative Delivery
Whether your needs are short-term bridge, emergency or supplemental or long-term system deployment, Newterra has flexible solutions that alleviate the need for major capital expenditure.
Media Services
From licensed and certified removal, to exchange, to supply, Newterra provides the gamut of services to keep your media and membrane solutions at peak performance. Let the same experts who build your systems help you keep them running.
Technical and Support Services
From operations consultation and long-term service contracts embowered by our Internet of Things (IoT) platform to commissioning expertise and emergency ad-hoc needs almost anywhere in the world, our technical experts are available to serve you. Let Newterra keep your systems optimized.
Parts and Customer Experience
Rely on Newterra for all your aftermarket needs. Our teams have the background and tools to serve you effectively. Nothing beats original equipment manufacturer (OEM) service. Anything you need, we’re here for you.
Technical Specifications
Newterra’s granular activated carbon (GAC) and activated carbon media products are available in coal, coconut shell, and wood base materials across a range of mesh sizes, covering liquid phase, vapor phase, active, and non-active filtration applications.
| Liquid Phase Activate Carbon Media | Product Name | GAC Base Material | Mesh Size | Activity |
|---|---|---|---|---|
| Activated Carbon Filter Media | Newterra 5D 1240 | Coal | 12 x 40 | 950 |
| Activated Carbon Filter Media | Newterra 5DR 0830 | Coal | 8 x 30 | 750 |
| Activated Carbon Filter Media | Newterra 5DC 0830 NSF | Coconut Shell | 8 x 30 | 1,100 |
| Activated Carbon Filter Media | Newterra 5DC 1230 NSF | Coconut Shell | 12 x 30 | 1,050 |
| Activated Carbon Filter Media | Newterra 5DW 1435 | Wood | 14 x 35 | 900 |
| Activated Carbon Filter Media | Newterra 5DAW 1240 | Coal | 12 x 40 | 950 |
| Activated Carbon Filter Media | Newterra 5DCAW 1240 | Coconut Shell | 12 x 40 | 1,150 |
| Vapor Phase Activate Carbon Media | Product Name | GAC Base Material | Mesh Size | Activity |
|---|---|---|---|---|
| Activated Carbon Filter and Other Filter Media | Newterra 5C 0410 | Coal | 4 x 10 | 60 |
| Activated Carbon Filter and Other Filter Media | Newterra 5CP 4mm 60 | Coal | 4 mm | 60 |
| Activated Carbon Filter and Other Filter Media | Newterra 5CR 0410 | Coal | 4 x 10 | 60 |
| Activated Carbon Filter and Other Filter Media | Newterra 5CC 0408 | Coconut Shell | 4 x 8 | 60 |
| Activated Carbon Filter and Other Filter Media | Newterra SAFE | Coal | 4 x 10 | 60 |
| Activated Carbon Filter and Other Filter Media | Newterra ZEUS | Coal | 4 x 10 | 60 |
| Impregnated Activated Carbon Media | Newterra MRA | All GAC | 4 x8 or 4 mm | 60 |
| Impregnated Activated Carbon Media | Newterra HP | All GAC | 4 x8 or 4 mm | 60 |
| Active Media | Product Name | Base Material | Mesh Size | Activity |
|---|---|---|---|---|
| Ammonia and Sulfur Odor Media | Newterra KLS | Clinoptilolite | 4 x 8 or 12 x 40 | 6% |
| Oil Absorption Media | Newterra OMC Oil Absorption | Anthracite, Modified Zeolite | 8 x 30 | 30% Active Ingredient |
| Oil Absorption Media | Newterra OMC-P Oil Absorption | Modified Zeolite | 4 x 10 | 100% Active Ingredient |
| Metals Removal Media | Newterra ARM | Ferric | 28 x 48 | 1% |
| Metals Removal Media | Newterra ANI | Resin | 16 x 40 | – |
| Metals Removal Media | Newterra CAT | Resin | 16 x 45 | – |
| Metals Removal Media | Newterra MRM | Hydroxyapatite | 20 x 60 | 5-15% |
| Non-Active Media | Product Name | Base Material | Mesh Size | Activity -Nominal (NOM) |
|---|---|---|---|---|
| Sand Garnet Zeolite Filter Media | ZM | Zeolite | 14 x 20 | <5 Micron NOM |
| Sand Garnet Zeolite Filter Media | Media Pack A | Sand, gravel | Various | 10 Micron NOM |
| Sand Garnet Zeolite Filter Media | Media Pack B | Sand, gravel, garnet | Various | 5 Micron NOM |
| Sand Garnet Zeolite Filter Media | Media Pack C | Sand, gravel, anthracite | Various | 10 Micron NOM Higher Capacity |
| Sand Garnet Zeolite Filter Media | Media Pack D | Sand, gravel, garnet, anthracite | Various | 5 Micron NOM Higher Capacity |
